TrXuS STS - Bias

The TrXus STS (Three Stage Sidewall) is a distinctively designed tire that created a whole new level for all-terrain tires.  The TrXuS STS is an all-terrain tire designed to give the consumer, who spends a lot of time on the road in their truck, jeep or SUV, a tire that works well on the street and offers good off-road performance.  The TrXuS STS is an all-terrain tire and although it is not intended to be a substitute for the Super Swamper or Bogger it does excel in snow and sand.  The unique tread pattern of the TrXus STS, with its uncanny ability to “hook-up” in loose dirt has proven to be a beast in truck pulling competitions.

The TrXuS STS all-terrain tire has a distinctive side wall design that compliments the unique tread pattern.  Together this package offers on and off road performance that’s as good as the tire looks.  The Interco TrXuS STS all-terrain tire is available in both a bias and radial versions and is offered in an array of size combinations including those vehicles running large diameter wheels.

Rim Diameter: 15

SKU Size Aspect Ratio Section Width Weight Tire Tread Width Tire Tread Depth Tread Ply Rating Side Wall Ply Side Wall Lettering Minimum Rim Width Maximum Rim Width O.D. C.S. Revs/Mile Max PSI Max Load D.O.T. Approved
STS-02 33x13.5/15LT 33 13.5 55 10 19/32 6 4 BSW 10 10 33.00 13.2 618 30 2300 Yes
STS-16 39.5x15/15LT 39.5 15 92 12 21/32 6 4 BSW 10 12 38.80 16.1 474 25 2550 Yes
STS-21 44x21/15LT 44 21 139 15 23/32 6 4 RWL 14 14 43.60 21.0 354 25 3200 Yes
STS-31 44x21/15LT 44 21 139 15 23/32 6 4 BSW 14 14 43.60 21.0 354 25 3200 Yes

Rim Diameter: 16

SKU Size Aspect Ratio Section Width Weight Tire Tread Width Tire Tread Depth Tread Ply Rating Side Wall Ply Side Wall Lettering Minimum Rim Width Maximum Rim Width O.D. C.S. Revs/Mile Max PSI Max Load D.O.T. Approved
STS-04 33x13.5/16LT 33 13.5 58 10 19/32 8 4 BSW 10 10 33.00 12.8 618 45 2800 Yes
STS-17 39.5x15/16LT 39.5 15 101 12 21/32 8 6 BSW 10 12 39.00 15.5 469 35 3100 Yes
STS-22 44x21/16LT 44 21 150 15 23/32 8 6 RWL 14 14 43.60 21.0 354 35 3500 Yes
STS-32 44x21/16LT 44 21 150 15 23/32 8 6 BSW 14 14 43.60 21.0 354 35 3500 Yes

Rim Diameter: 16.5

SKU Size Aspect Ratio Section Width Weight Tire Tread Width Tire Tread Depth Tread Ply Rating Side Wall Ply Side Wall Lettering Minimum Rim Width Maximum Rim Width O.D. C.S. Revs/Mile Max PSI Max Load D.O.T. Approved
STS-18 39.5x15/16.5LT 39.5 15 99 12 21/32 8 6 BSW 10 12 39.00 16.3 469 35 3105 Yes
STS-23 44x21/16.5LT 44 21 148 15 23/32 8 6 RWL 14 14 43.60 21.0 354 35 3525 Yes
STS-33 44x21/16.5LT 44 21 148 15 23/32 8 6 BSW 14 14 43.60 21.0 354 35 3525 Yes

Rim Diameter: 17

SKU Size Aspect Ratio Section Width Weight Tire Tread Width Tire Tread Depth Tread Ply Rating Side Wall Ply Side Wall Lettering Minimum Rim Width Maximum Rim Width O.D. C.S. Revs/Mile Max PSI Max Load D.O.T. Approved
STS-19 39.5x15/17LT 39.5 15 96 12 21/32 8 6 BSW 10 12 39.00 15.2 469 35 3050 Yes
STS-24 44x21/17LT 44 21 142 15 23/32 8 6 RWL 14 14 43.60 21.0 354 35 3300 Yes
STS-34 44x21/17LT 44 21 142 15 23/32 8 6 BSW 14 14 43.60 21.0 354 35 3300 Yes

Rim Diameter: 20

SKU Size Aspect Ratio Section Width Weight Tire Tread Width Tire Tread Depth Tread Ply Rating Side Wall Ply Side Wall Lettering Minimum Rim Width Maximum Rim Width O.D. C.S. Revs/Mile Max PSI Max Load D.O.T. Approved
STS-20 39.5x15/20LT 39.5 15 91 12 21/32 8 4 RWL 10 12 39.50 14.5 456 35 3000 Yes
STS-35 44x21/20LT 44 21 138 15 22/32 8 6 BSW 16 16 43.80 20.0 352 35 3300 Yes
STS-40 39.5x15/20LT 39.5 15 91 12 21/32 8 4 BSW 10 12 39.50 14.5 456 35 3000 Yes
Share

DISCLAIMER: Every effort has been made to verify the accuracy of the listed specifications. Interco Tire Corporation cannot be held responsible for any discrepancies and as such this information should be considered as approximate.  As much as we would like to help, we cannot and will not give advice on fitting our tires to any particular vehicle.  Ride height changes due to age and use does not allow for steadfast rules.  Your local retailer may be able to help by inspecting your vehicle first hand.  Tread and side wall patterns may vary by tire size.
